Globalprotect Client Command Line

VPN provides you with secure access to University services and the Internet when you are off-campus. Northwestern is transitioning to a new VPN platform called GlobalProtect. GlobalProtect replaces three existing VPN clients: built-in VPN clients, Cisco AnyConnect, and Pulse Secure SSL VPN. For details on the transition, see https://www.it.northwestern.edu/about/it-projects/vpn-migration-2019/overview.html. Please note that if you are a member of the Feinberg School of Medicine, you will continue to use your built-in VPN client.
The portal address for GlobalProtect is vpn-connect.northwestern.edu.
GlobalProtect requires you to authenticate with your NetID and NetID password and Duo multi-factor authentication. If you need to register a phone for multi-factor authentication, see Registering and managing your devices for Duo multi-factor authentication.

GlobalProtect for macOS

DEBUG is another command you can run. In general for the exams, MP = management plane. MS = Management server. CP = Control Plane. All of the above are names for the same thing, the management part of the firewall, you will see them around, like ms.log or mp-log. Open a command line VPN e.g. VPN Client Management Command use FortiClient SSL VPN: nmcli con. Start — So you am trying to get vpn cli.exe connect tc- vpn Command - line Start Connection to Connect/disconnect from VPN from The full FortiClient installation ' mode and then set up to work Jump to 'AccountConnect': Start Windows client command.

If your University-owned computer is managed by your department, you may not need to set up GlobalProtect. If you see the GlobalProtect icon () in your menu bar, skip the set-up instructions and go directly to connect to GlobalProtect.

Set up GlobalProtect

Note that your Mac must be running macOS Catalina (10.15), Mojave (10.14), High Sierra (10.13), or Sierra (10.12).

Go to https://chocolate.ci.northwestern.edu/Software/Titles/NU_Global_Protect/5.1.4/MacOS/GlobalProtect-5.1.4.pkg to download the GlobalProtect installation package.
Within your computer's Downloads folder, double-click the downloaded file to begin installation. When prompted, click Continue, then click Install.
If you see a prompt about a PaloAlto system extension being blocked, click Open Security Preferences.
1. Click Allow, then close your preferences window.
2. If prompted, enter your computer's administrative user name and password, then click Install Software. If you don't have administrative rights to your University-owned computer, contact your departmental tech support personnel.
3. Restart your Mac.
When the installation finishes, you will be prompted to move the installer the trash.
You will then be prompted asking for your keychain password. Enter your password and choose Always Allow.
Click Close. Once installation is complete, GlobalProtect will appear in your menu bar at the top of your macOS desktop.

Connect to GlobalProtect

Click the GlobalProtect icon in the menu bar, enter portal address vpn-connect.northwestern.edu, then click Connect.
When prompted, enter your NetID and NetID password, then confirm your identity with Duo multi-factor authentication. You will then be connected to GlobalProtect.
To disconnect, click the GlobalProtect icon again, then click Disconnect.

GlobalProtect for Windows

If your University-owned computer is managed by your department, you may not need to set up GlobalProtect. If you see the GlobalProtect icon () in your system tray, skip the set-up instructions and go directly to connect to GlobalProtect.

Set up GlobalProtect

Note that your computer must be running Windows 7 or later. If you don't have administrative rights to your University-owned computer to install software, contact your departmental tech support personnel.

Go to https://chocolate.ci.northwestern.edu/Software/Titles/NU_Global_Protect/5.1.4/Windows/GlobalProtect64-5.1.4.msi to download the GlobalProtect installation package.
From your computer's Downloads folder, double-click the installer, then click Next to follow the installation instructions.
When prompted for a portal address, enter vpn-connect.northwestern.edu.
Once installation is complete,
- GlobalProtect will appear in the lower left area of your system tray.
- GlobalProtect will automatically prompt you to connect to VPN.

Connect to GlobalProtect

Click the GlobalProtect icon in the system tray, then click Connect. If nothing seems to happen when you click Connect, see Fixing when clicking Connect in GlobalProtect VPN for Windows does nothing.
When prompted, enter your NetID and NetID password, then confirm your identity with Duo multi-factor authentication. You will then be connected to GlobalProtect.
To disconnect, click the GlobalProtect icon again, then click Disconnect.

GlobalProtect for iOS (iPhone and iPad)

Set up GlobalProtect

Note that your device must be running iOS 10 or later.

From the App Store, find and download GlobalProtect
When you open the app, you will be prompted for a portal address. Enter vpn-connect.northwestern.edu.
When prompted to allow GlobalProtect to set up a VPN configuration, tap Allow.

Connect to GlobalProtect VPN

Open GlobalProtect and tap Connect.
When prompted, enter your NetID and NetID password, then confirm your identity with Duo multi-factor authentication. You will then be connected to GlobalProtect.
To disconnect, open GlobalProtect again, then tap Disconnect.

GlobalProtect for Android

Set up GlobalProtect

Note that your device must be running Android v5.0 or later.

From Google Play, find and download GlobalProtect
When you open the app, you will be prompted for a portal address. Enter vpn-connect.northwestern.edu.
When prompted to allow GlobalProtect to set up a VPN connection, tap OK.

Connect to GlobalProtect VPN

Open GlobalProtect and tap Connect.
When prompted, enter your NetID and NetID password, then confirm your identity with Duo multi-factor authentication. You will then be connected to GlobalProtect.
To disconnect, open GlobalProtect again, then tap Disconnect.

GlobalProtect for Linux

Supported Linux versions

Because Northwestern's GlobalProtect requires Duo Mobile multi-factor authentication (MFA), only GUI versions of the GlobalProtect can be used on Linux systems. You cannot use the command line (CLI) interface. Given that requirement, these Linux versions are the only supported operating systems:

Ubuntu 18.04.3 LTS
Ubuntu 18.04.2 LTS
Ubuntu 19.04
Red Hat Enterprise Linux 7.0 - 7.7
CentOS 7.0 - 7.7

Set up GlobalProtect

Download the GlobalProtectinstallation package for your Linux system.
- RHEL 7/centOS: https://chocolate.ci.northwestern.edu/Software/Titles/NU_Global_Protect/5.2.4/Linux/GlobalProtect_UI_rpm-5.2.4.0-14.rpm
- Ubuntu/Debian: https://chocolate.ci.northwestern.edu/Software/Titles/NU_Global_Protect/5.2.4/Linux/GlobalProtect_UI_deb-5.2.4.0-14.deb
Open the terminal on your device and install GlobalProtect. Note that the commands may vary depending on your version of Linux.
- RHEL 7/centOS CLI commands:
  yum install https://dl.fedoraproject.org/pub/epel/epel-release-latest-7.noarch.rpm
  yum localinstall --nogpgcheck GlobalProtect_UI_rpm-5.2.4.0-14.rpm
- Ubuntu/Debian CLI commands:
  sudo apt-get install libqt5webkit5
  sudo dpkg -i GlobalProtect_UI_deb-5.2.4.0-14.deb
When prompted for a portal address, enter vpn-connect.northwestern.edu.
Once installation is complete, GlobalProtect will appear in your menu bar at the top of your Linux system.

Connect to GlobalProtect

Click the GlobalProtect icon in the menu bar, enter the portal address (vpn-connect.northwestern.edu), then click Connect.
When prompted, enter your NetID and NetID password, then confirm your identity with Duo multi-factor authentication. You will then be connected to GlobalProtect.
To disconnect, click the GlobalProtect icon again, then click Disconnect.
If you are not seeing the Global Protect icon in your menu bar, there is a CLI command to bring it up:
1. On the terminal prompt, enter 'globalprotect launch-ui' (NOTE: It may take longer than expected to see the Online Passport page to appear in the next step)
2. This will bring up the windows above
3. You can use this if you need to connect and don't see the icon, or to bring up the icon when you need to disconnect.

GlobalProtect for ChromeOS

Set up GlobalProtect

Go to the Google Play Store to download the GlobalProtect installation package.
Open the installer, then follow the installation instructions.
When prompted for a portal address, enter vpn-connect.northwestern.edu.
Once installation is complete, GlobalProtect will automatically prompt you to connect to VPN.

Connect to GlobalProtect

Open GlobalProtect and click Connect.
When prompted, enter your NetID and NetID password, then confirm your identity with Duo multi-factor authentication.
When the Connection request message appears, click OK to make a VPN connection on your device.

Globalprotect Vpn Client Command Line

Below is a list of commands for “> show global-protect-gateway” that are currently available: (Each give specific information that will be valuable depending on what is being examined)

Command	Description
current-satellite	Show current GlobalProtect gateway satellites
current-user	Show current GlobalProtect gateway users
flow	Show dataplane GlobalProtect gateway tunnel information
flow-site-to-site	Show dataplane GlobalProtect site-to-site gateway tunnel information
gateway	Show list of GlobalProtect gateway configuration
previous-satellite	Show previous GlobalProtect gateway satellites
previous-user	Show previous user session for GlobalProtect gateway users
statistics	Show statistics of current GlobalProtect gateway users

Examples

Some of the commands are listed below with the expected outputs.

Additional Information
The CLI quickstart guide provides other available CLI commands.
